PJ630B
<
>
PJ630B

PJ630B

Customizable according to technical specifications / Technical-parameter-based customization available.

Email:

falan@falantrading.com

Categories:

Agricultural Spraying Drone

Product name: Agricultural crop-protection UAV
Model: ZFJN630
Configuration: 6-axis, 6-rotor
Max payload: 30 kg
Wheelbase: 2 028 mm
Take-off weight: 66.8 kg
Empty weight: 22 kg
No-load endurance: 15–20 min
Unfolded size: 2 692 mm × 2 619 mm × 885 mm (without propellers)
Folded size: 1 192 mm × 620 mm × 885 mm
Propulsion: X9Plus motor
Propeller: 36 in
Flight controller: Jiyi K++ V2
Hover accuracy: ±1.5 m horizontal / ±0.5 m vertical
Max tilt angle: 30°
Max yaw rate: 150°/s
Wind resistance: steady 4 / gust 5
Flight modes & safety: GPS, AB-line, waypoints, one-key return, failsafe (return/continue), low-battery protection, geo-fence, flight-log auto-save, auto-motor-lock on landing, no-fly zone, GPS-loss protection, empty-tank protection
Equipped with HD camera, FPV & telemetry links, built-in searchlight for night ops, screen-equipped remote, real-time back-end data monitoring.
