LY30-Xingtai Falan Trading Co., Ltd.

LY30

The new operating system hardware protection has been upgraded and the performance is stable. Equipped with a water-cooled centrifugal nozzle that can control the atomization particle size and a large-flow impeller pump, the flow rate is abundant. Truss structure, the strength of the fuselage is doubled, the internal structure is optimized, and it is firmly resistant to falling.

Customizable according to technical specifications / Technical-parameter-based customization available.

Email:

falan@falantrading.com

Categories:

Agricultural Spraying Drone

Basic Info

Product wheelbase 2000mm
Expand size 1710 * 1453* 700mm
Folding size 603 * 1120 * 700mm
Load of 30kg
The total weight of the machine is 30kg
Maximum weight 68kg
Spray flow rate 12L/min
Effective spray width of 4-8M
Flight speed 3m/s
Empty flight for 30 minutes
Full load flight for 20 minutes
Working voltage 58.8V
Battery capacity 30000mah
Time limited homework of 50 mu

Maximum ascent speed: 2 m/s

Maximum descent speed: 2 m/s
Horizontal flight speed:
Positioning mode: 5m/s
Sports mode: 8m/s
Attitude mode: 20m/s
Flight attitude stability:
Pitch angle ≤± 3 °
Roll angle ≤± 3 °
Yaw angle ≤± 3 °
Maximum tilting angle:
Positioning mode: 30 °
Sports mode: 45 °
Attitude mode: 35 °
Maximum rotational angular velocity: 120 °/s
Maximum rotation angle: 360 °
Maximum tolerable wind speed: Level 7
Maximum flight speed: 70KM/H
Body material: Carbon fiber material, lightweight, high strength, and corrosion-resistant.
Control method: APP ground station/remote control
Flight indicator lights: capable of distinguishing the nose and tail of the aircraft.
Operation time: From transportation state to flight state ≤ 2 minutes(2 people)
Flight status light: LED lights indicate the flight status, and different colors or frequencies of LED lights can provide feedback on the cause and warning of faults such as battery status and hardware failures.

Factory

Company certificate

Packing & Delivery

We have cooperated with experienced shipping forwarders for many years, they arrange the shipment. No matter by express, by air or by sea, we will track the course of the goods all the way, to make sure goods arrive at you on time and in good condition.

GET A QUOTE

Whether you have any questions about our products, please feel free to contact us, we will reply as soon as possible.
