Products

Configuration: 8-Axis, 16-Propeller
Empty Weight: 224 kg
Battery Weight: 136 kg
Maximum Takeoff Weight: 680 kg
Standard Payload: 300 kg
Maximum Payload: 320 kg
Folding Mechanism: Arms fold downward
Folded Dimensions: 1900 x 1900 x 1800 mm
Unfolded Dimensions (Excluding Propellers): 4600 x 4600 x 1800 mm
Flight Endurance: 25 min (No Payload); 12 min (Full Payload)
Maximum Flight Distance: 15 km (No Payload); 8 km (Full Payload)
Maximum Ascent Speed: 5 m/s
Maximum Descent Speed: 2 m/s
Maximum Horizontal Flight Speed: 15 m/s
Maximum Flight Altitude: 300 m
Maximum Operating Elevation: 4000 m
Satellite Positioning: GPS + Galileo + BeiDou + GLONASS
Maximum Wind Resistance: Level 7
Operating Temperature Range: -20°C to 50°C
Overall Protection Rating: IP34
Remote Controller: 1 Unit
Batteries: 1 Set of 24S Batteries (8 Units)
Chargers: 1 Set of Chargers (4 Units)

Factory

Company certificate

Packing & Delivery

We have cooperated with experienced shipping forwarders for many years, they arrange the shipment. No matter by express, by air or by sea, we will track the course of the goods all the way, to make sure goods arrive at you on time and in good condition.
